Home /Products/Auto Parts Manufacturing/Anodized Auto Parts Manufacturing Sustainable Engine Brackets Mounts

Anodized Auto Parts Manufacturing Sustainable Engine Brackets Mounts

100
MOQ
0.5-15$
Price
Anodized Auto Parts Manufacturing Sustainable Engine Brackets Mounts
Features Gallery Product Description Chat Now
Features
Specifications
Certifications: IATF 16949, ISO 9001
Material: A380 Aluminum Alloy (optional ADC12, A356)
Casting Method: High-pressure Die Casting (hot & Cold Chamber), Squeeze Casting Available
Secondary Machining: 3- To 5-axis CNC Milling & Turning, Drilling, Tapping, Deburring
Dimensional Tolerance: ± 0.05 Mm (post-machining)
Highlight:

Anodized Auto Parts Manufacturing

,

Anodized auto parts production

,

Sustainable Auto Parts Manufacturing
Basic Infomation
Place of Origin: China
Brand Name: HUARONGDA
Model Number: HRD-APM-5
Payment & Shipping Terms
Packaging Details: Box
Delivery Time: 7-15days
Supply Ability: 10000pcs/Days
Product Description
Custom Aluminum Die Cast Auto Parts – Engine Brackets & Mounts
Technical Specifications
Parameter Specification
Certifications IATF 16949, ISO 9001
Material A380 aluminum alloy (optional ADC12, A356)
Casting Method High-pressure die casting (hot & cold chamber), squeeze casting available
Secondary Machining 3- to 5-axis CNC milling & turning, drilling, tapping, deburring
Dimensional Tolerance ± 0.05 mm (post-machining)
Surface Roughness Ra 0.8 µm (standard); Ra 0.4 µm achievable
Maximum Dimensions Up to 500 × 400 × 250 mm
Part Weight Range 0.1-8 kg
Surface Finishes Anodizing, powder coating, PVD plating, sand- or bead-blasting, chemical passivation
File Formats Accepted 2D: DWG, DXF, PDF; 3D: STEP, IGES, STL
Minimum Order Quantity 1 piece (prototype); scalable to mass production
Lead Time Prototype: 7-10 days; Production: 15-25 days
Quality Control 100% CMM inspection, SPC monitoring, X-ray porosity testing, tensile & hardness testing

Key Advantages
  • Automotive-Grade Quality: Fully IATF 16949 and ISO 9001 certified processes ensure consistent, defect-free engine brackets and mounts.
  • Robust A380 Alloy: High-strength, corrosion-resistant aluminum alloy delivers exceptional vibration damping and load-bearing capacity.
  • Precision CNC Finishing: Post-cast machining holds critical mounting faces and bolt patterns to ± 0.05 mm for perfect fit and alignment.
  • Low MOQ & Rapid Prototyping: Validate designs with a single sample; receive detailed quotes within 24 hours and prototypes in under two weeks.
  • Comprehensive In-House Workflow: End-to-end capabilities from mold design through CNC machining and surface finishing—no third-party delays.

Industry Trends
  • Hybrid Manufacturing: Merging additive-manufactured cores with die casting for complex internal geometries.
  • Next-Gen Alloys: Adoption of metal-matrix composites and aluminum-lithium alloys for reduced weight.
  • Industry 4.0 Smart Factories: IoT-enabled presses and CNC centers for real-time process monitoring.
  • Sustainable Production: Closed-loop cooling and energy-efficient machines to minimize environmental impact.

Applications
  • Engine Mounting Systems: Rigid brackets to secure engine blocks and damp vibration under high-load conditions.
  • Accessory Supports: Mounts for alternators, compressors, and air-conditioning pumps with precise bore alignment.
  • Transmission & Drivetrain: Robust support brackets for transmission cases and differential housings.
  • Aftermarket Performance: Lightweight, reinforced mounts for racing and high-performance applications.
  • Off-Road & Heavy-Duty Vehicles: Corrosion-resistant brackets designed for rugged environments.

Frequently Asked Questions
What is the minimum order quantity?
We can produce a single prototype part; volume production scales from dozens to thousands.
Which CAD formats do you support?
2D drawings in DWG/DXF/PDF and 3D models in STEP, IGES, STL are all accepted.
How tight are your tolerances?
Standard post-machining tolerances are ± 0.05 mm; tighter tolerances down to ± 0.02 mm can be arranged.
Can you handle both casting and CNC machining in-house?
Yes—our fully integrated facility covers die casting, CNC machining, heat treatment, and finishing for turnkey delivery.
What surface treatments are available?
Options include anodizing, powder coating, PVD plating, sand- or bead-blasting, and chemical passivation.
What is the typical lead time?
Prototype samples in 7-10 days; full production runs in 15-25 days after mold approval.
Tag:

die casting automotive parts

automobile casting components

cnc machining car parts
