Home /Products/Aluminum Die Casting/High Pressure Aluminum Die Casting High Accuracy Metal Parts Zinc Alloy Solutions

High Pressure Aluminum Die Casting High Accuracy Metal Parts Zinc Alloy Solutions

100
MOQ
0.5-15$
Price
High Pressure Aluminum Die Casting High Accuracy Metal Parts Zinc Alloy Solutions
Features Gallery Product Description Chat Now
Features
Specifications
Materials: ADC12 & A380 Aluminum Alloys, Zamak/zinc Alloy, Stainless Steel Grades Upon Request
Tolerances: As Tight As ± 0.02 Mm (per CT4–CT7 Standards)
Design Support: Free DFM Analysis; Accepts STEP, IGES, DWG, DXF Files
Highlight:

High Pressure Aluminum Die Casting

,

High Pressure aluminium alloy die casting

,

High Accuracy Aluminum Die Casting
Basic Infomation
Place of Origin: China
Brand Name: HUARONGDA
Model Number: HRD-ADC-6
Payment & Shipping Terms
Packaging Details: Box
Delivery Time: 7-15days
Supply Ability: 10000pcs/Days
Product Description
Precision Investment & High-Pressure Die-Cast Metal Parts – Custom Aluminum & Zinc Alloy Solutions
Product Specifications
Materials ADC12 & A380 aluminum alloys, Zamak/zinc alloy, stainless steel grades upon request
Tolerances As tight as ± 0.02 mm (per CT4–CT7 standards)
Design Support Free DFM analysis; accepts STEP, IGES, DWG, DXF files
Product Parameters
  • Materials: ADC12 & A380 aluminum alloys, Zamak/zinc alloy, stainless steel grades upon request
  • Part Size & Weight: From 5 g up to 8 kg; dimensions up to 800 × 800 × 200 mm
  • Process:
    • Investment (Lost-Wax) Casting: Silica-sol or water-glass slurry for intricate geometries
    • High-Pressure Die Casting: Cold-chamber machines (200 - 1,600 ton) for high-volume runs
  • Tolerances: As tight as ± 0.02 mm (per CT4-CT7 standards)
  • Surface Quality:
    • Roughness: Ra 1.6 - 6.3 µm (after shot- or sand-blasting)
    • Finishes: Powder coating, anodizing, electrophoretic painting, plating (Ni, Cu, Zn, Cr), polishing, silk-screen or laser marking
  • Certifications: ISO 9001:2015, RoHS, CE; material test reports (MTR), First-Article Inspection (FAI) available
  • Design Support: Free DFM analysis; accepts STEP, IGES, DWG, DXF files
  • MOQ & Packaging: Prototype from 1 pc; bulk in foam-lined cartons or wooden crates

Key Selling Points
  1. Dual-Process Expertise
    Combines the fine detail of investment casting with the speed and economy of high-pressure die casting.
  2. Ultra-Tight Precision
    Maintains repeatable tolerances down to ± 0.02 mm, reducing or eliminating post-machining.
  3. Versatile Alloy Options
    From lightweight aluminum to durable zinc and stainless steel, tailored to strength, weight and corrosion requirements.
  4. One-Stop OEM/ODM Service
    End-to-end workflow: pattern & mold design, casting, CNC machining, heat treatment, surface finishing and assembly.
  5. Robust Quality Assurance
    100% inspection via CMM, X-ray/ultrasonic testing, spectrometer analysis and pressure/leak testing ensure compliance with global standards.

Future Trends
  • Additive-Hybrid Tooling: SLA/DLP 3D-printed patterns for faster prototype iteration and complex core geometry.
  • Sustainable Casting: Increased use of recycled alloys and eco-friendly binders to meet circular-economy goals.
  • Smart Factory Integration: IIoT sensors on die-casting machines for real-time monitoring, predictive maintenance and digital twins.

Application Scenarios
Industry Typical Applications
Electronics & Telecom Base-station enclosures, heat-sink housings
Automotive & EV Sensor brackets, transmission components
Medical Devices Surgical instrument bodies, implant fixtures
Industrial Machinery Pump impellers, valve bodies, gearbox shells
Consumer Products Power-tool housings, decorative hardware

Frequently Asked Questions
Q1: Can I order a single prototype piece?
A: Yes—MOQ is 1 pc. Rapid prototypes available in 7-10 days.
Q2: What are your standard lead times?
A: Prototypes in 7-10 days; mass production in 15-30 days after sample approval (depending on volume & complexity).
Q3: Which CAD formats do you support?
A: STEP, IGES, DWG, DXF—3D models preferred for fastest tooling development.
Q4: How do you control porosity and surface integrity?
A: Investment casting uses controlled slurry and sintering; die casting employs vacuum-assist and optimized gating to minimize gas entrapment.
Q5: What surface treatments can you apply?
A: Powder coating, anodizing, electrophoretic paint, plating, polishing, blasting, silk-screen and laser marking.
Q6: How are parts packed and shipped?
A: Packed in foam-lined cartons or on wooden pallets; FOB, CIF or DDP shipping terms available to suit your logistics needs.
Tag:

aluminum pressure die casting

die cast aluminum alloys

aluminium casting service
