Home /Products/Metal Surface Treatment/1–5mm Thickness Powder Coated Aluminum Panels Custom RAL Color Matching RoHS

1–5mm Thickness Powder Coated Aluminum Panels Custom RAL Color Matching RoHS

100
MOQ
0.5-15$
Price
1–5mm Thickness Powder Coated Aluminum Panels Custom RAL Color Matching RoHS
Features Gallery Product Description Chat Now
Features
Specifications
Material: Aluminum 5052, 6061, 1100, Or Custom Grades
Panel Thickness: 1.0 Mm – 5.0 Mm
Panel Size: Customizable Up To 1500mm × 3000mm
Surface Finish: Polyester/TGIC Powder Coating (Electrostatic Spraying)
Color Matching: RAL & Pantone Custom Matching Available
Standards: ISO 9001, RoHS, REACH, AAMA 2603 / 2604 (upon Request)
MOQ: 50 Panels Or Based On Project Size
Lead Time: 7–15 Days Depending On Volume And Finish
Highlight:

RoHS Powder Coated Aluminum Panels

,

custom aluminum sheet panel

,

custom Powder Coated Aluminum Panels
Basic Infomation
Place of Origin: China
Brand Name: HUARONGDA
Model Number: HRD-MST-7
Payment & Shipping Terms
Packaging Details: Box
Delivery Time: 7-15days
Supply Ability: 10000pcs/Days
Product Description
Powder Coated Aluminum Sheet Metal Panels | RAL Color Matching | 5 Years Outdoor Warranty
Product Specifications
Attribute Value
Material Aluminum 5052, 6061, 1100, or custom grades
Panel Thickness 1.0 mm – 5.0 mm
Panel Size Customizable up to 1500mm × 3000mm
Surface Finish Polyester/TGIC Powder Coating (Electrostatic Spraying)
Color Matching RAL & Pantone custom matching available
Standards ISO 9001, RoHS, REACH, AAMA 2603 / 2604 (upon request)
MOQ 50 panels or based on project size
Lead Time 7–15 days depending on volume and finish
Technical Parameters
Parameter Specification
Material Aluminum 5052, 6061, 1100, or custom grades
Panel Thickness 1.0 mm - 5.0 mm
Panel Size Customizable up to 1500mm × 3000mm
Surface Finish Polyester/TGIC Powder Coating (Electrostatic Spraying)
Color Matching RAL & Pantone custom matching available
Coating Thickness 60-100 μm
Gloss Levels Matte (10-30 GU), Satin (30-60 GU), Glossy (60-90 GU)
Outdoor Durability 5-Year Color & Finish Warranty
Corrosion Resistance Excellent - Salt Spray ≥ 1000h (ASTM B117)
UV Resistance Yes - UV-stable powder formulation
Application Temperature -40°C to +120°C
Standards ISO 9001, RoHS, REACH, AAMA 2603 / 2604 (upon request)
Optional Treatments Brushed, perforated, embossed, CNC cutouts
MOQ 50 panels or based on project size
Lead Time 7-15 days depending on volume and finish

Key Selling Points
  • RAL Color Customization
    Match any architectural or brand color using RAL or Pantone codes for complete design freedom.
  • Durable Powder Coated Finish
    Electrostatic powder coating provides a smooth, UV-resistant, corrosion-proof surface ideal for outdoor use.
  • 5-Year Outdoor Warranty
    Guaranteed resistance to color fading, chalking, and peeling under normal outdoor conditions.
  • Weather & Corrosion Protection
    Salt spray resistance ≥1000 hours and UV stabilization make it suitable for coastal and high-sunlight regions.
  • Versatile Fabrication
    Panels can be laser cut, CNC punched, bent, or embossed for use in diverse architectural or industrial settings.

Future Trends in Powder Coated Aluminum Panels
  • Super Durable Polyester & Fluoropolymer Coatings
    Increasing adoption of PVDF and high-performance polyester for 10-20 year warranties.
  • Sustainable Coating Systems
    Eco-friendly powder coatings with lower VOCs and improved recyclability.
  • Digital Printing + Powder Coating Hybrid Finishes
    Integration of photo-realistic digital prints beneath clear powder coats for signage and branding.
  • Functional Coatings
    Development of self-cleaning, anti-graffiti, or anti-bacterial coatings in architectural panels.

Application Scenarios
  • Architectural Cladding
    Used in building facades, soffits, balcony panels, and decorative wall treatments.
  • Electrical and Control Enclosures
    Sheet metal panels for electrical cabinets and industrial enclosures that require corrosion resistance.
  • Retail & Signage
    Color-matched panels for branded retail displays, kiosks, and illuminated signs.
  • HVAC and Ventilation Systems
    Durable external covers and vents exposed to the elements in commercial systems.
  • Transport & Equipment Housings
    Vehicle side panels, generator covers, or machinery guards that need a robust finish.

Frequently Asked Questions
Q1: What's the advantage of powder coating over wet paint?
A1: Powder coating offers a more durable, uniform, and eco-friendly finish without solvent emissions. It's more resistant to UV, corrosion, and chipping.
Q2: Can you do both flat and bent sheet metal panels?
A2: Yes. We support custom sheet metal fabrication including bending, perforation, and 3D shapes.
Q3: How accurate is the RAL color matching?
A3: We use professional powder suppliers with certified RAL matching--typically within Delta E ≤ 1.0 for color precision.
Q4: Are the panels safe for marine/coastal environments?
A4: Yes. Panels are corrosion-resistant with salt spray performance ≥1000 hours. For extreme marine use, we also offer pre-anodizing undercoats.
Q5: Can logos or patterns be added to the panels?
A5: Absolutely. We offer laser engraving, perforation, silk printing, and CNC cutouts for branding or design customization.
Q6: Do you offer installation support or mounting systems?
A6: Yes. We can provide pre-drilled panels, mounting flanges, and optional subframe designs depending on your installation method.

Choose our powder coated aluminum sheet metal panels for long-lasting color, weather resistance, and design flexibility. Whether for architecture, industry, or branding --your ideas deserve a durable finish.
