High Pressure Die Cast Aluminum Housings With Type III Anodizing IP67 Rating

100
MOQ
0.5-15$
Price
High Pressure Die Cast Aluminum Housings With Type III Anodizing IP67 Rating
Features Gallery Product Description Chat Now
Features
Specifications
Material: A380, ADC12, Or Customized Aluminum Alloy
Casting Method: High Pressure Die Casting (HPDC)
Surface Finish: Type III Hard Anodizing (MIL-A-8625, ASTM B580 Compliant)
Waterproof Rating: IP67 (Dust-tight & Submersible Up To 1 Meter For 30 Min)
Dimensions: Customizable Up To 300 Mm In Any Direction
MOQ: 100 Units; Prototype From 1 Piece
Lead Time: 10–15 Business Days For Production
Highlight:

High Pressure Die Cast Aluminum Housings

,

High Pressure Die Cast Housing

,

Anodizing Die Cast Aluminum Housings
Basic Infomation
Place of Origin: China
Brand Name: HUARONGDA
Model Number: HRD-MST-6
Payment & Shipping Terms
Packaging Details: Box
Delivery Time: 7-15days
Supply Ability: 10000pcs/Days
Product Description
High Pressure Die Cast Aluminum Housings with Type III Anodizing | IP67 Rating & 1000h Salt Spray Test
Product Specifications
Material A380, ADC12, or customized aluminum alloy
Casting Method High Pressure Die Casting (HPDC)
Surface Finish Type III Hard Anodizing (MIL-A-8625, ASTM B580 compliant)
Waterproof Rating IP67 (Dust-tight & submersible up to 1 meter for 30 min)
Dimensions Customizable up to 300 mm in any direction
MOQ 100 units; prototype from 1 piece
Lead Time 10–15 business days for production

Technical Parameters
Parameter Specification
Anodizing Thickness 50 ±5 μm
Salt Spray Resistance ≥ 1000 hours (ASTM B117 tested)
Wall Thickness Min. 2 mm
Tolerances ±0.02 mm post-machining
Color Options Black, dark gray, bronze (Type III-compatible dyes)
Operating Temperature -40°C to +125°C
Secondary Machining CNC milling, drilling, tapping, threading, countersinking
Coating Features Non-conductive, abrasion-resistant, corrosion-proof
Certifications ISO 9001, IATF 16949, RoHS, REACH

Key Features
  • All-Weather Durability - Engineered to perform in extreme environmental conditions, thanks to IP67 protection and a Type III anodized shell.
  • Superior Corrosion Resistance - Over 1000 hours of salt spray test performance ensures long-term reliability in coastal, chemical, or humid environments.
  • Type III Hard Anodized Protection - Ultra-tough 50 μm coating delivers high hardness (>400 HV) and wear resistance--ideal for industrial use.
  • Precision Fit & Machining - CNC post-processing ensures tight tolerances, making the housing perfect for sealing critical electronics or sensors.
  • Custom Form Factor - Available in various shapes and sizes for different applications--choose flat back plates, ribbed exteriors, and internal bosses.

Industry Trends
  • Integrated Sealing Features - More housings are being designed with built-in gaskets or overmolded seals for enhanced waterproofing.
  • Hybrid Die Casting - Combination of aluminum die cast cores with polymer or composite overlays for weight reduction and signal transparency.
  • Thermal Management Designs - Housings are evolving to include heat sinks, thermal pads, or embedded cooling channels for high-power electronics.
  • Low Carbon Footprint Castings - Green manufacturing and recycled alloy usage are gaining momentum in industrial applications.

Applications
  • Outdoor Electrical Equipment - Enclosures for lighting controllers, power inverters, and junction boxes exposed to harsh weather.
  • Industrial Automation Systems - Housings for PLCs, sensors, motor drivers, and machine control units that require durability and precision.
  • Telecom and Networking Devices - Casing for outdoor signal boosters, Wi-Fi access points, and 5G base units needing waterproofing and RF shielding.
  • Automotive & EV Components - Battery management systems, sensor units, and motor controllers that must withstand vibration, heat, and humidity.
  • Defense and Aerospace Electronics - Mission-critical electronic housings requiring non-corrosive, lightweight, and robust packaging.

Frequently Asked Questions
Q1: What's the benefit of Type III anodizing on a die cast part?
A1: Type III anodizing creates a hard, corrosion-resistant surface layer that drastically improves wear and chemical resistance--ideal for demanding environments.
Q2: Are these housings truly waterproof?
A2: Yes. With IP67 rating, they are dust-tight and can be submerged in up to 1 meter of water for 30 minutes.
Q3: Can I customize the internal layout?
A3: Absolutely. We offer fully customized internal boss placement, standoffs, mounting holes, and cable routing channels.
Q4: Is there thermal protection available?
A4: Yes. We can integrate heat dissipation fins or design the housing as a passive heat sink depending on your thermal load requirements.
Q5: What's the typical turnaround time?
A5: Samples are usually ready within 7-10 days. Production runs ship within 10-15 business days depending on complexity.
Q6: Can I get a prototype before bulk production?
A6: Yes. We support prototyping and small-batch runs before transitioning to large-scale manufacturing.
Looking for rugged and waterproof die cast housings that can withstand real-world abuse? Our Type III anodized aluminum enclosures are built for performance, protection, and precision. Contact us today to discuss your custom project.
